OEM PN: 7Y943-000
OEM: Penberthy
Direct Replacement PN: DL964
100% interchangeable / compatible
Summary
The Penberthy 7Y943-000 is a high-pressure probe manufactured by Penberthy. This probe is common in a number of systems that were part of a partnership gone wrong or copied by other companies. Fossil Aquarian, Tyco, Yarway, and Penberthy all share this common design. The pricing on the OEM parts is extremely high for no real reason. The DL964 is a direct replacement for all these probes and is available at a much lower price, but with the same quality and warranty. Even though the rating is 370 degrees C and 210 bar. These probes are routinely used for super-heated steam applications (560 deg C and 300 bar).Key Features
Drumline Part Number: DL964Replaces: Penberthy 7Y943-000
- Max Pressure:210 bar / 3000psi
- Max Temperature:370 Deg C / 700 F
- Construction:Zirconia insulator
- Material:Stainless steel
- Testing: Electrical, helium, hydro
Product Description
Penberthy 7Y943-000
The Penberthy 7Y943-000 is a high-pressure probe manufactured by Penberthy. This probe is common in a number of systems that were part of a partnership gone wrong or copied by other companies.
Fossil Aquarian, Tyco, Yarway, and Penberthy all share this common design. The pricing on the OEM parts is extremely high for no real reason. The DL964 is a direct replacement for all these probes and is available at a much lower price, but with the same quality and warranty. Even though the rating is 370 degrees C and 210 bar. These probes are routinely used for superheated steam applications (560 deg C and 300 bar).
The OEM probe is constructed using brazed 304 stainless steel and zirconia insulator. 304 stainless steel is not the best material to use for probe construction. The thermal expansion coefficient (rate of expansion with increase in temperature) of the two materials does not match well and it leaves the probe susceptible to failure at the brazed joint. Drumline use materials that are more closely matched in terms of thermal expansion coefficient, which results in a more reliable probe.
Product Specification
| CHARACTERISTIC | Drumline DL964 |
|---|---|
| Penberthy P/N | 7Y943-000 |
| Body Material | Stainless steel |
| Insulator Material | Brazed Zirconia |
| Maximum Temperature | 370 Deg C / 700 F |
| Maximum Pressure | 210 bar / 3000psi |
| Warranty | 2 Years |
| Country of Origin | United Kingdom |
| Customs Code | 902690 |
